Microwave Motion Sensor, 180/360, 5-15m, 300W/250V, 0.1-2000lux, 5.8GHz CW Radar, ISM

Microwave motion sensor, indoor, wall-mounted, 180/360 degrees, 5-15m, 300W/250V, 0.1-2000lux, 5.8GHz CW radar, ISM band, white


Features:
UV resistant.
Suitable for energy-saving lamps.
The detection distance can be set from 5 to 15 meters.
Delay time adjustable, can be set for 10s, 30s, 90s, 3min, 6min and 12min.


Technical specification:
Detection angle: 180°/ 360°.
Power: 220V-240V AC.
Frequency: 50/60 Hz.
HF system: 5.8GHz CW radar, ISM band.
Load: 300W/ 200W.
Detection distance: 5-15 m radius (adjustable).
Delay time: from 10s ±3s to 12min ±1min (adjustable).
Ambient light: < 0.1-2000 lux (adjustable). Installation height: 1.5-3.5 m. Dimensions: 86.4x60.4x98 mm. Material: PC. Safety class: IP54. Color: white. Weight: 156g.

Warranty: 24 months.
