Power supply 48V, 2A ADS-110DL-52-1

Power supply 48V 2A 96W for DAHUA NVRs with PoE.


Features:
Power supply adapter for Dahua devices such as PoE switches or DVRs with built-in PoE switch, the power consumption of which doesnt not exceed 96W.


Note: Please pay attention to proper cooling conditions of the power adapter during operation!


Technical data:
Model: ADS-110DL-52-1 480096G.
Output current: 2A.
Output voltage: 48V DC.
Output power: 96W.
Input voltage: 100-240 V AC, 50/60 Hz.
Max. Input current: 1.5A.
Plug: 6.5/4.3/1.4 mm plug with center pin.
Connector: C15.
LED indicators: none.
Housing: Desktop, plastic.
Operating temperature: 0 – 55°C.
Relative humidity: 10 – 90%RH.
Weight: 0.35 kg.
Dimensions: 157 x 59 x 34 mm.


Warranty: 24 months.
