ZKTECO RFID Card Reader 125KHz / 13.56MHz, Wiegand 26/34, KR310

RFID card reader 125 KHz / 13.56MHz (Mifare Classic, Mifare Desfire), Wiegand 26/34.
Features:
125 KHz / 13.56MHz ISO14443A card reader suitable for Mifare Classic, Mifare Desfire cards.
With its elegant and robust design, the reader is easy to plug in and install and can be easily mounted on a metal door frame.
Supports one door control from both sides. LED (red, green) indicator shows allowed / denied access.
IP65 waterproof and with an operating temperature range of -10°C to +70°C, it is suitable for both indoor and outdoor installation.


Technical specification:
Operating frequency: 13.56 MHz.
Compatible with: Mifare Classic, Mifare Desfire.
Reading range: up to 10cm (125KHz), up to 5cm (13.56MHz).
Reading time: up to 300ms.
Output protocol: Wiegand 34 / 66bit.
Current: <70mA. Voltage: 6-14V DC. Safety class: IP65. Material: ABS, PC. Operating temperature: -10°C~+70°C. Operating humidity: 10% - 90% RH. Dimensions: 77.5 x 42.8 x 16.5 mm. Cable length: 1.5m.

Warranty: 24 months.
